Overview
The Laowa Aksen 17.5mm f/1.7 5-10X Ultra Macro APO Lens for FUJIFILM X provides a 5:1 to 10:1 magnification range for photographing very small subjects. It features a fixed 0.9" working distance from the front of the lens and an internal parfocal zoom design that maintains sharp focus throughout the magnification range.
Its compact form factor is suitable for handheld shooting or use on a motorized focus stacking rig.
Features
- Full-frame lens format coverage
- f/1.7 to f/5.6 aperture range
- Fixed focus type
- 17 elements in 12 groups
- No image stabilization
- Lightweight, compact design
Included
- Venus Optics Laowa Aksen 17.5mm f/1.7 5-10x Ultra Macro APO Lens (FUJIFILM X)
Specifications
| Focal Length | 17.5mm |
|---|---|
| Aperture | Maximum: f/1.7 Minimum: Not Specified by Manufacturer |
| Lens Mount | FUJIFILM X |
| Lens Format Coverage | Full-Frame |
| Minimum Focus Distance | From Front of Lens: 0.9" / 22.5 mm |
| Magnification | 10:1 Macro Reproduction Ratio 5 to 10x Magnification |
| Optical Design | 17 Elements in 12 Groups |
| Aperture/Iris Blades | 11 |
| Focus Type | Fixed Focus |
| Image Stabilization | No |
| Dimensions | 2.8 x 5" / 70.2 x 127.5 mm (Diameter x Length) |
| Weight | 1.3 lb / 570 g / 0.59 kg |
| Package Weight | 2.445 lb / 1.11 kg |
| Box Dimensions (LxWxH) | 9 x 7.2 x 4.4" |
