Overview
Offering 200 drive and distortion types—the most ever packed into a single stompbox—the Zoom MS-200D+ is a go-to powerhouse for guitarists who crave high-gain versatility. It includes 150 brand-new original effects along with 36 emulations of classic overdrives, distortions, boosts, fuzz tones, and more, giving you virtually unlimited options for shaping your sound.
The MS-200D+ lets you save and recall over 200 user patches, and you can chain two effects together—such as pairing a boost with an overdrive—to craft distinctive distortion textures. Operation is straightforward thanks to four easy-to-use encoder knobs and foot-operated cross switches that allow hands-free control. An integrated chromatic tuner keeps your tuning accurate without extra gear. Plus, with USB-C support for the Handy Guitar Lab iOS app, you can access an expanding library of patches, drives, and distortion models.
Specifications
| Presets |
250 User Patch Memories
|
| Sampling Rate |
24-Bit / 44.1 kHz (128x Oversampling)
|
| DSP |
32-Bit
|
| Frequency Response |
20 Hz to 20 kHz (±0.5 dB)
|
| Input Level |
-20 dBu
|
| Input Impedance |
Line: 470 Kilohms
|
| Maximum Output Level |
+7.2 dBu
|
| Signal-to-Noise Ratio |
122 dB
|
| Noise Floor |
-100 dBu
|
| Panel Type |
LCD
|
| Native Resolution |
160 x 128
|
| Touchscreen |
No
|
| USB I/O |
1 x USB-C Female Input/Output
|
| Audio I/O |
1x 1/4″ TS Hi-Z/Instrument Input
1x 1/4″ TS Hi-Z/Instrument Output |
| Power Source |
AC Adapter with Power Brick, Battery
|
| Battery Type |
2x AA
|
| DC Input Power |
9 VDC at 500 mA
|
| Operating Current |
500 mA (Typical)
|
| Color |
Yellow
|
| Material of Construction |
Metal
|
| Environmental Resistance |
No
|
| Dimensions |
5.2 x 3.1 x 2.4″ / 13.3 x 7.9 x 6.1 cm (D x W x H)
|
| Weight |
12.2 oz / 346 g (Without Batteries)
13.9 oz / 393 g (With Batteries) |
| Package Weight |
0.955 lb
|
| Box Dimensions (LxWxH) |
6.3 x 3.3 x 3″
|
