Shimbol ZO600M 5.5″ 1080p60 Wireless HDMI Touchscreen Recorder/Monitor
€340.00 excl. BTW
- 1920 x 1080 Touchscreen Display
- Up to 1080p60 HDMI Video Input
- Up to 1080p60 Recording to microSD Card
- 1000 cd/m² Brightness
- 500′ Wireless Range, 3D LUT Support
- Waveform, Vectorscope, Focus Peaking
- Markers, False Color, Color Temperature
- Embedded Audio, 3.5mm Headphone Port
- Power via 2 x L-Series/F970 or DC Input
- 1/4″-20 Thread Mount
External warehouse, approximately 10 days or more
Overview
The ZO600M 5.5″ Wireless HDMI Touchscreen Recorder/Monitor from Shimbol offers the ability to monitor and record video in up to 1080p60 resolution with applied 3D LUTs. Serving as both a transmitter and receiver, it seamlessly integrates with Shimbol wireless transmitter and receiver systems, and it supports video transmission to iPhone or iPad devices. Equipped with a 5.5″ 1920 x 1080 touchscreen display, the device includes an HDMI 2.0 input, an HDMI output, and a 3.5mm headphone jack for embedded audio output. The display boasts 1000 cd/m² brightness and supports advanced features such as 3D LUTs, luma waveform, vectorscope, zoom, focus peaking, and more, enhancing its functionality and versatility.
Wireless Transmission
- This flexible monitor/recorder functions as both a transmitter and receiver.
- Compatible with Shimbol wireless video transmitters and receivers (sold separately).
- Capable of transmitting video directly to iPhones and iPads.
- Offers up to 500′ line-of-sight wireless range.
Recording Monitor
- The ZO600M allows you to monitor and record video at resolutions up to 1080p60.
- Supports live LUT application with customizable 3D LUT uploads and adjustments.
- Features recording and playback capabilities for versatile workflows.
HDMI Input/Output
- Easily connects to camcorders or cinema cameras via the HDMI input.
- Includes a 3.5mm headphone jack for monitoring embedded audio.
Bright Touchscreen
- Equipped with an intuitive touchscreen interface for seamless operation.
- The 1000 cd/m² brightness ensures excellent visibility, even in bright environments.
3D LUT Support
- Custom 3D LUTs can be uploaded via the integrated micro-SD card slot for precise color grading.
Imaging Features
- Includes advanced tools like a luma waveform, vectorscope, and histogram.
- Offers features such as focus peaking, false color, and exposure checks.
- Supports additional functions like check fields, selectable markers, RGB adjustment, zoom, and gamma curve selection.
Mounting Options
- The ZO600M can be securely mounted using its 1/4″-20 threaded hole located on the bottom.
Specifications
Display
| Panel Type |
LCD
|
| Display Size |
5.5″ / 14.0 cm
|
| Native Resolution |
1920 x 1080
|
| Aspect Ratio |
16:9
|
| Touchscreen |
Yes
|
| Maximum Brightness |
1000 nits / cd/m2
|
| Contrast Ratio |
1200:1
|
| HDR Support |
Yes
|
| Pixels Per Inch (ppi) |
400 ppi
|
| LUT Support |
Yes
|
| Image Controls |
Anamorphic De-Squeeze, Color Temperature Selection, False Color, Focus Peaking, Histogram, RGB Parade, Screen Markers, Vectorscope, Waveform, Zebra
|
Inputs / Outputs
| Video I/O |
1x HDMI 1.4a Input
1x HDMI 1.4a Output |
| Audio I/O |
1x 1/8″ / 3.5 mm Headphone Output
|
| Built-In Speaker |
No
|
| Power I/O |
1x Barrel (16.8 VDC) Input
1x Barrel (0.8 A / 7.4 VDC) Output |
| Other I/O |
1x USB-C (Firmware)
|
| Media/Memory Card Slot |
Single Slot: microSD/microSDHC/microSDXC [Supports Recording]
|
| File System Support |
FAT32
|
| Wireless Range |
500′ / 152.4 m
|
| Frequency Range |
5.1 to 5.8 GHz
|
| Latency |
80 ms
|
| RF Power |
17 dBm
|
| RF Sensitivity |
-80 dBm
|
| Wi-Fi |
Wi-Fi 5 (802.11ac)
|
| Bluetooth |
No
|
| Mobile App Compatible |
Yes: iOS Only
App Name: Shimbol |
Format Support
| Video Format |
HDMI
1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 |
| Audio Format |
48 kHz
|
| Wireless Video Compression |
Compressed
|
| Timecode Support |
No
|
Recording
| Pulldown Conversion |
No
|
| Camera Trigger |
No
|
| Pre-Roll Record |
No
|
| Encoding Formats |
x
H.264 |
| Closed Caption Support |
No
|
| Reference Input |
No
|
Power
| Input Power |
7 to 16.8 VDC
|
| Battery Type |
2x L-Series
|
| Power Consumption |
8 W
|
Mounting
| Mounting |
1x 1/4″-20 Female (Bottom)
|
General
| Environmental Resistance |
No
|
| Certifications |
FCC, CE, RoHS, Kcc, TELEC
|
| Storage Conditions |
-4 to 140°F / -20 to 60°C
|
| Material of Construction |
Plastic
|
| Dimensions |
5.9 x 4.1 x 1.2″ / 151 x 103 x 29.5 mm
|
| Weight |
10.58 oz / 300.00 g
|
