Shimbol Memory I Pro 5.5″ 3D LUT HDMI & 3G-SDI Touchscreen Video Recorder/Monitor
€469.00 excl. BTW
- 1920 x 1080 Touchscreen Display
- Up to DCI 4K25 HDMI, 1080p60 3G-SDI
- 1080p60 MP4 File Recording to SD Card
- 2000 cd/m² Brightness
- Improved UI Interface, 3D LUT Support
- HDR Monitoring, Waveform
- Real-Time Focusing, Custom RGB Settings
- Cold Shoe Mount, 1/4″-20 Thread
- Embedded Audio, 3.5mm Headphone Port
- NP-F Battery Plate, DC Input
External warehouse, approximately 10 days or more
Overview
With enhanced features and an intuitive user interface, the Memory I Pro 5.5″ HDMI & 3G-SDI Touchscreen Recorder/Monitor from Shimbol offers the capability to record and display up to DCI 4K25 video via HDMI or 1080p60 via 3G-SDI, all while supporting custom 3D LUTs. This Pro monitor features a 5.5″ 1920 x 1080 touchscreen display with a wide 178° viewing angle, a 1200:1 contrast ratio, and a 2000 cd/m² brightness, ensuring clear visibility even in direct sunlight. Its versatile interface includes HDMI and 3G-SDI inputs and outputs, a USB-C port for debugging, a 3.5mm headphone jack for embedded audio monitoring, and an SD card slot for direct recording. The updated UI and touchscreen controls make it easy to access multiple visual assist functions.
Features
- Supports recording and playback with 3D LUTs
- Supports real-time HDMI and 3G-SDI recording
- Built-in player for internal review
- Optional bit rate recording
- Focus your image in real-time, view focus peaking
- Updated high-precision waveform
- False color adjustment
- Power the Memory I Pro with its L-series battery plate and compatible NP-F970 battery. A DC input supports other external power supplies.
- A 1/4″-20 thread on the monitor allows you to mount it onto the included cold shoe mount, which can tilt the display for improved visibility.
In The Box
Shimbol Memory I Pro 5.5″ 3D LUT HDMI & 3G-SDI Touchscreen Video Recorder/Monitor
Cold Shoe Mount Adapter
SD Card
Tempered Screen Protector
HDMI Cable
SDI Cable
Limited 14-Month Manufacturer Warranty
Specifications
| Panel Type |
LCD
|
| Display Size |
5.5″ / 14.0 cm
|
| Native Resolution |
1920 x 1080
|
| Aspect Ratio |
16:9
|
| Viewing Angle |
Horizontal: 178°
Vertical: 178° |
| Touchscreen |
Yes
|
| Maximum Brightness |
2000 nits / cd/m2
|
| Contrast Ratio |
1200:1
|
| HDR Support |
Yes, Hybrid Log Gamma
|
| Pixels Per Inch (ppi) |
400 ppi
|
| Image Controls |
Check Field, Color Temperature Selection, Customizable Aspect Ratios, False Color, Image Flip, Screen Markers, Waveform, Zebra
|
| Video I/O |
1x HDMI 1.4 Input
1x BNC (3G-SDI) Input 1x HDMI 1.4 Output 1x BNC (3G-SDI) Output |
| Audio I/O |
1x 1/8″ / 3.5 mm Headphone Output
|
| Built-In Speaker |
No
|
| Power I/O |
1x Barrel Input
|
| Other I/O |
1x USB-C (Firmware)
|
| Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC
|
| Wi-Fi |
No
|
| Bluetooth |
No
|
| Mobile App Compatible |
No
|
| Video Format |
HDMI
DCI 4K: 25/24/23.98 UHD 4K: 30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SDI 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 |
| Gamma Curve |
Rec709
|
| Timecode Support |
Yes
|
| Pulldown Conversion |
No
|
| Camera Trigger |
SDI, HDMI
|
| Pre-Roll Record |
No
|
| Encoding Formats |
Up to 1920 x 1080
H.264 at up to 60 fps |
| Input Power |
6.5 to 16.8 VDC
|
| Built-In Battery |
No
|
| Battery Type |
1x L-Series
|
| Power Consumption |
12 W
|
| Mounting |
2x 1/4″-20 Female
|
| Operating Conditions |
14 to 104°F / -10 to 40°C
|
| Storage Conditions |
-4 to 140°F / -20 to 60°C
|
| Material of Construction |
Aluminum
|
| Dimensions |
5.8 x 3.4 x 1″ / 146.6 x 87.6 x 26.5 mm
|
| Weight |
11.29 oz / 320.00 g
|
