PORTKEYS High Bright Monitor 7 inch – HD7H

Überblick

The Portkeys HD7H is our most affordable 7-inch on-camera monitor. This HDMI-only monitor can take video signals up to 4K30p, is daylight-viewable with a maximum brightness of 1,000nits, and can be easily be powered for hours by a single Sony NP-F battery or externally via its power input port. Whether you’re starting your filmmaking journey or looking for a budget-friendly second monitor, the Portkeys HD7H has you covered with all the essential professional monitoring tools you can expect.

Features

• 7-inch, 8-bit panel with a resolution of 1280 x 720 and a 1000:1 contrast ratio.
• Maximum brightness of 1,000nits.
• 1 x HDMI input, 1 x 3.5mm audio output, 1 x AV input.
• Built-in loudspeaker.
• Maximum input resolutions: 4K DCI at 24p or 4K UHD at 30p.
• Professional monitoring tools: Luma Histogram, False Color, Peaking.
• Anamorphic de-squeeze: 1.33x, 1.5x, 2.0x, and custom aspect ratio from 0.25 to 4.0x.
• Powered via a single Sony NP-F style battery or 5.5mm barrel connector 7.4V-24V power input.
• Low power draw: only 10W.
• Lightweight and rugged ABS and PC housing: only 278g/9.8oz.

In The Box

• 1x Portkeys HD7H Monitor
• 1x Sunshade rubber cover
• 1x HD7H sunshade
• 1x A to A HDMI Cable
• 1 x A to D HDMI cable
• 1 x AV cable
• 1 x Monitor mount
• 1 x Manual
• 1 x Customer feedback card

Specifications

The HD7H features a 7-inch display with a maximum brightness of 1,000nits, making it an excellent monitoring solution, no matter if you’re shooting indoors or in bright daylight conditions. Also, it has a vast 178° viewing angle thanks to a frosted screen with anti-glare coating.

The panel’s resolution is 1280 x 720, it covers 75% of the Rec.709 color space and has a 1000:1 contrast ratio.
