Panoramica
The Silver Edition lenses maintain the modern, mechanically reliable performance that sets the Orion Series apart from vintage anamorphic lenses, all while celebrating aspects of the silver screen cinema era. Precision-adjusted air space tunings paired with bold Silver Edition coatings result in expressive, reactive, yet chromatically refined anamorphic flares unlike any lens before.
The Orion Silver Edition can be custom manufactured on an as-ordered basis.
E' dotato di porte di ingresso e uscita
- Low distortion for an incredibly wide lens
- 124º horizontal field-of-view with 2x anamorphic squeeze
- 18” (1.5’) close focus
- Covers traditional anamorphic 4:3 film and digital sensor formats up to 24.89mm x 18.66mm and covers full-frame formats edge-to-edge with Atlas 1.6x LF Extender
Specifiche
| Lunghezza Focale | 21mm |
| T-Stop Range | T2-T16 |
| Format | Super 35 |
| Image Circle* | Ø31mm* |
| Attacco obiettivo | PL (Interchangable) |
| Min. Focus | 1.5ft .45m |
| Diametro anteriore | 136mm |
| Filetto del filtro | N/A |
| Iris Blades | 14 |
| Hortizontal Fov | 124° |
| Materiale del corpo | Anodized Aluminum |
| Lunghezza | 7.4″ / 18.7cm |
| Peso | 6.9 lbs / 3.1kg |
