Überblick
Extending coverage beyond traditional full-frame sensors, these professional-grade optics deliver a consistent 1.5x anamorphic squeeze ratio. Featuring interchangeable ARRI PL and Canon EF lens mounts, the system easily adapts to various camera platforms using optional bayonets. Additionally, compatibility with MOFAGE POCO drop-in filters enhances versatility, making this lens an exceptional choice for high-end cinematography and filmmaking projects.
Included
Panasonic Lumix G97 Mirrorless Camera
Panasonic Lumix G Vario 12-60mm f/3.5-5.6 ASPH. POWER O.I.S. Lens
Li-Ion Battery Pack (7.2V, 1200mAh)
Battery Charger
USB Cable
Shoulder Strap
Hot Shoe Cover
Body Cap
Cover for Battery Grip Connector
Specifications
| Lens Mount |
Micro Four Thirds
|
| Sensor Resolution |
Actual: 21.77 Megapixel
Effective: 20.3 Megapixel (8176 x 1920) |
| Image Sensor |
17.3 x 13 mm (Four Thirds) MOS
|
| Sensor Crop (35mm Equivalent) |
Crop Factor: 2x
*Additional Crop Occurs in Select Video Modes |
| Image Stabilization |
Sensor-Shift, 5-Axis
|
| Built-In ND Filter |
No
|
| Capture Type |
Stills & Video
|
| Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
|
| Shutter Speed |
Electronic Shutter
1/16000 to 1 Second Electronic Front Curtain Shutter 1/2000 to 60 Seconds |
| Bulb/Time Mode |
Bulb Mode
|
| ISO Sensitivity Range |
200 to 25,600 (Extended: 100 to 25,600) Video 200 to 6400 in Auto Mode (Extended: 100 to 6400) |
| Metering Method |
Center-Weighted Average, Multiple, Spot
|
| Exposure Modes |
Aperture Priority, Auto, Manual, Program, Shutter Priority
|
| Exposure Compensation |
-5 to +5 EV (1/3 EV Steps)
|
| Metering Range |
0 to 18 EV
|
| White Balance |
Presets: Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4
|
| Continuous Shooting |
Up to 9 fps at Maximum Resolution for up to 30 Frames (Raw) / 600 Frames (JPEG)
|
| Interval Recording |
Yes
|
| Self-Timer |
10-Second Delay
|
| Aspect Ratio |
1:1, 3:2, 4:3, 16:9
|
| Image File Format |
JPEG, Raw
|
| Internal Recording Modes |
AVCHD
1920 x 1080p at 24.00/60.00 fps [24 to 28 Mb/s]1920 x 1080i at 60.00 fps [17 to 29.98 Mb/s]MP4 UHD 4K (3840 x 2160) at 24.00/30.00 fps [100 Mb/s]1920 x 1080p at 30.00/60.00 fps [20 to 28 Mb/s]1280 x 720 at 30.00 fps [10 Mb/s] |
| External Recording Modes |
HDMI
DCI 4K (4096 x 2160) |
| Fast-/Slow-Motion Support |
Slow-Motion Only
|
| Recording Limit |
No
|
| IP Streaming |
No
|
| Built-In Microphone |
Stereo
|
| Audio Recording |
AAC Audio
|
| Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC (UHS-II)
|
| Video I/O |
1x Micro-HDMI Output
|
| Audio I/O |
1x 1/8″ / 3.5 mm TRS Stereo Headphone Output
1x 1/8″ / 3.5 mm TRS Stereo Microphone Input |
| Power I/O |
1x USB-C Input
|
| Other I/O |
1x USB-C Data Output (Shared with Power Input)
1x 2.5 mm Sub-Mini Remote Input |
| Wireless |
Wi-Fi 4 (802.11n), Bluetooth 5.0
|
| Mobile App Compatible |
Yes: Android & iOS
App Name: Panasonic Image App Functionality: Access Stored Files, Remote Control, View Live Feed |
| Global Positioning (GPS, GLONASS, etc.) |
GPS
*Via Connected Smartphone |
| Display Size |
3.0″
|
| Resolution |
1,840,000 Dot
|
| Display Type |
Articulating Touchscreen OLED
|
| Type |
Electronic (OLED)
|
| Resolution |
2,360,000 Dot
|
| Eye Point |
20 mm
|
| Coverage |
100%
|
| Magnification |
Approx. 0.74x
|
| Diopter Adjustment |
-4 to +4
|
| Focus Type |
Auto and Manual Focus
|
| Focus Mode |
Automatic, Continuous-Servo AF, Flexible, Manual Focus
|
| Autofocus Points |
Contrast Detection: 49
|
| Built-In Flash/Light |
Yes, Flash Only
|
| Flash Modes |
Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction
|
| Guide Number |
9′ / 2.7 m at ISO 200
|
| Maximum Sync Speed |
1/200 Second
|
| Flash Compensation |
-3 to +3 EV (1/3 EV Steps)
|
| Dedicated Flash System |
TTL
|
| External Flash Connection |
Shoe Mount
|
| Batterie |
1x Rechargeable Lithium-Ion, 7.2 VDC, 1200 mAh (Included)
• Approx. 290 Shots |
| Shoe Mount |
1x Hot Shoe
|
| Tripod Mounting Thread |
1x 1/4″-20 Female (Bottom)
|
| Material of Construction |
Magnesium Alloy
|
| Operating Conditions |
14 to 104°F / -10 to 40°C at 10 to 80% Humidity
|
| Dimensions (W x H x D) |
5.1 x 3.7 x 3″ / 130.4 x 93.5 x 77.4 mm
|
| Weight |
1.1 lb / 478 g (Body Only)
1.2 lb / 530 g (With Battery, Recording Media) |
| Focal Length |
12 to 60mm (35mm Equivalent: 24 to 120mm)
|
| Maximum Aperture |
f/3.5 to 5.6
|
| Minimum Aperture |
f/22
|
| Angle of View |
84.05° to 20.44°
|
| Maximum Magnification |
0.27x
|
| Minimum Focus Distance |
7.87″ / 20 cm
|
| Optical Design |
11 Elements in 9 Groups
|
| Diaphragm Blades |
7, Rounded
|
| Focus Type |
Autofocus
|
| Image Stabilization |
Yes
|
| Filter Size |
58 mm (Front)
|
| Dimensions (ø x L) |
2.6 x 2.8″ / 66 x 71 mm
|
| Weight |
7.4 oz / 210 g
|
Compatibility
