Accsoon Cineview M7 Pro 7″ Recording Monitor with Wireless Tx/Rx
€798.00 exkl. MwSt.
- Edge-Lit 7″ Multi-Touch Display
- Integrated Dual-Band Wi-Fi RX/TX
- 1920 x 1080 Resolution
- 1000 cd/m² Brightness
- 3G-SDI & HDMI I/O up to DCI 4K60
- Up/Down & SDI to HDMI Cross Conversion
- 3D LUTs, Color Grading, Image Management
- SD Card, USB Flash, SSD Storage Options
- Power via Dual L-Series Plates, USB-C
- SmartOS with File Management
18 stock in external warehouse, usually ships 1-2 days.
Add pro cinema monitoring tools to your camera with the CineView M7 Pro 7″ Recording Monitor with Wireless Transmitter/Receiver from Accsoon. This bright, 7″ on-camera multi-touch display offers 1920 x 1080 resolution, wireless streaming and receiver functions, 1000 cd/m² brightness, numerous imaging tools, and the ability to input and output up to DCI 4K60 video via HDMI and up to 1080p60 via 3G-SDI.
Included
- Accsoon CineView M7 Pro 7″ Recording Monitor with Wireless Transmitter/Receiver
- 4 x Antenna
- Limited 1-Year Manufacturer Warranty
Specifications
| Panel Type |
LCD
|
| Display Size |
7.0″ / 17.8 cm
|
| Native Resolution |
1920 x 1080
|
| Aspect Ratio |
16:9
|
| Viewing Angle |
Horizontal: 176°
Vertical: 176° |
| Touchscreen |
Yes
|
| Maximum Brightness |
1000 nits / cd/m2
|
| Contrast Ratio |
1000:1
|
| HDR Support |
Yes
|
| Color Gamut |
100% Rec. 709
|
| LUT Support |
Yes
|
| Image Controls |
Anamorphic De-Squeeze, False Color, Focus Peaking, Histogram, Image Flip, Image Freeze, Pixel Zoom, Screen Markers, Vectorscope, Waveform, Zebra
|
| Antenna I/O |
4x RP-SMA Female
|
| Video I/O |
1x BNC (3G-SDI) Input
1x BNC (3G-SDI) Output 1x HDMI 2.0 Input 1x HDMI 2.0 Output |
| Embedded Audio |
HDMI/SDI
|
| Audio I/O |
1x 1/8″ / 3.5 mm Mic Input
1x 1/8″ / 3.5 mm Headphone Output |
| Built-In Speaker |
No
|
| Power I/O |
1x Barrel 2.1 mm (16.8 VDC) Input
1x USB-C (9 VDC / 3 A) Input 1x USB-C (5 VDC / 2 A) Output |
| Media/Memory Card Slot |
Single Slot: SD (Unspecified Type) [Record/LUT/Firmware]
|
| Wireless Range |
1148.3′ / 350 m (Line-of-Sight)
|
| Latency |
60 ms
|
| Wi-Fi |
Unspecified Version; Dual-Band (2.4 & 5 GHz)
|
| Bluetooth |
Yes
|
| Mobile App Compatible |
No
|
| Video Format |
HDMI
DCI 4K: 60/59.94/50/30/29.97/25/24/23.98 UHD 4K: 60/59.94/50/30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SDI 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 |
| Video Signal Conversion |
SDI to HDMI
HDMI to SDI |
| Audio Format |
2-Channel 16-Bit 48 kHz
|
| Wireless Video Compression |
Compressed
|
| Timecode Support |
No
|
| Pulldown Conversion |
No
|
| Camera Trigger |
No
|
| Pre-Roll Record |
No
|
| Encoding Formats |
Up to 4096 x 2160
H.264 Up to 4096 x 2160 H.265 |
| Maximum Audio Tracks |
2
|
| Input Power |
6 to 16.8 VDC
9 to 15 VDC at 3 A |
| Batterie |
2x L-Series Mount on Fixed Plate
|
| Power Consumption |
12 W (Typical)
28 W (Maximum) |
| Tripod/Accessory Mounting |
2x 1/4″-20 Female
|
| Operating Conditions |
14 to 104°F / -10 to 40°C
|
| Material of Construction |
Aluminum
|
| Dimensions |
7.2 x 4.8 x 1.2″ / 182.2 x 120.7 x 31.5 mm
|
| Weight |
1.1 lb / 494.3 g, Excluding Antenna
|
| Package Weight |
1.74 lb
|
| Box Dimensions (LxWxH) |
8.2 x 5.8 x 2.3″
|
